高分子涂层是使用高分子树脂的高密度涂层,类似于日本独特的URUSHI(生漆)工艺,即反复的微薄的涂一层漆,晒干后继续涂覆。最多时需要几十层甚至上百层处理。高分子涂装正是应用了URUSHI的原理,上百遍的超薄喷涂之后,可以覆盖所有针孔,使涂层具有良好的绝缘、耐磨、防锈效果,同时具有优异的附着力等优点。 此外高分子涂层不含卤素,具有环保安全,颜色丰富等特点。

HI-DEN涂层固化后性能一览 COATING PROPERTY

耐热

heat resistance

250可连续工作,瞬间可以在300

Can work continuously at 250 ℃ , instantaneously at 300 ℃.

绝缘

insulation

最大可实现1.5KV/20µm(根据材料不同)

Max 1.5KV/20µm (varies from different material).

切割

cutting

涂装后可以切开产品而涂层不会剥落,因此可以实现微小铁芯绕线的自动化.

The cutting does not take away the surrounding coating. Therefore, the automation of small core winding can be realized.

防锈

anti-rust

SST试验500小时以上

SST test more than 500 hours.

粘接力

adhesion

是镀镍的5倍以上适用于稀土永磁

3 to 5 times higher than electroplating, good for rare earth magnet.

伸缩性

flexibility

防止微小铁芯的碎片飞散对周边部件产生影响。喷涂后金属片可以弯着而涂层不受影响

To prevent debris from dispersing tiny cores from affecting peripheral components. Sprayed metal sheets can bend without the coating being affected.

均匀涂层

uniform coated

产品的边角处皆可均匀涂覆适合于EMC铁芯的涂装

The edges and corners of the product can be evenly coated. Suitable for EMC core coating.

公差小

tiny tolerances

批量生产中的尺寸公差、偏差可控制到很小

Dimensional tolerances and deviations in batch production can be controlled to a very small extent.

颜色

color

可以调节成各种颜色,适用于利用颜色区分不同的电子产品,以及使饰品的具有独家特色

Can be adjusted to a variety of colors, suitable for the use of color to distinguish different electronic products, and make jewelry with exclusive features.

抗化学药剂

anti-chemical agent

可用于马达的碱性油中

Can be used in basic oil of motor.

无过敏性

no allergies

应用在医疗器械以及各种饰品(例如医疗器械胃镜的部件)

Used in medical devices and various accessories (such as components of medical instruments for gastroscopy).

RoHS,无卤素

halogen free

对应RoHS,以及卤素

halogen free, conform to RoHS standards.

L值(电感)

L value - inductance

喷涂过程中对产品的负担小,对于L值无大的影响

The burden on the product is small, and there is no big influence on the L value in the process of spraying.

强度

strength

铅笔硬度测试在5H以上

Pencil hardness test above 5 hours.
